A Unit Substation Transformer is an integrated power distribution system commonly used in industrial, commercial, and institutional applications. It offers a compact, cost-effective, and safe method to step down high-voltage electricity to usable low-voltage levels, typically for facility-wide power supply.
What is a Unit Substation Transformer?
A Unit Substation Transformer combines multiple components into a single system, including:
- Primary Medium Voltage Switchgear
- Power Transformer
- Secondary Low Voltage Switchgear
These components are assembled together in a close-coupled configuration to minimize wiring, reduce space usage, and streamline installation. It is typically used in indoor electrical rooms or dedicated substations.
Key Advantages
- Space-saving Design: Integrates all components in one compact footprint.
- Time-efficient Installation: Pre-configured and factory-tested assemblies reduce onsite labor.
- Improved Safety: Internal isolation barriers and arc-resistant enclosures enhance personnel protection.
- Customization: Flexible configurations available for different voltage classes and operational environments.
- High Reliability: Designed for heavy-duty, continuous operations with minimal maintenance.
Typical Applications
- Manufacturing plants
- Data centers
- Hospitals and campuses
- Shopping malls
- Commercial buildings
- Utility substations
- Warehouses and logistics parks
Technical Specifications (Example)
| Objet | Value |
|---|---|
| Rated Capacity | 500 kVA / 1000 kVA / 2000 kVA (custom) |
| Primary Voltage | 11 kV / 22 kV / 33 kV |
| Secondary Voltage | 400/230 V |
| Frequency | 50 Hz / 60 Hz |
| Transformer Type | Oil-immersed / Dry-type |
| Méthode de refroidissement | ONAN / ONAF |
| Tap Changer | Off-load or On-load |
| Insulation Class | A / B / F / H |
| Protection | Circuit breakers, relays, surge arresters |
| Enclosure Rating | IP23 / IP44 / IP54 |
Note: Custom configurations are available upon request.
Construction Variants
Depending on site requirements, unit substations can be supplied in the following formats:
- Indoor Metal-Enclosed Unit Substation
- Outdoor Pad-Mounted Unit Substation
- Skid-Mounted Modular Substation
Foire aux questions (FAQ)
Q1: What is the difference between a unit substation and a compact substation?
A : A unit substation is typically used indoors with metal-clad construction and modular components, while compact substations (mini substations) are more commonly used outdoors in a weatherproof enclosure.
Q2: Are unit substations suitable for high-rise buildings?
A : Yes. Due to their compact and modular design, unit substations are ideal for basement installations in commercial and residential towers.
Q3: Can I request a custom primary or secondary voltage?
A : Absolutely. Most manufacturers provide flexibility in voltage ratings, transformer types, and switchgear configurations.
Why Choose a Unit Substation?
A Unit Substation Transformer is an excellent solution for organizations looking for:
- Centralized power distribution
- Reduced electrical room footprint
- Simplified maintenance
- High system reliability
Whether you’re upgrading existing infrastructure or developing a new facility, unit substations provide an efficient and scalable solution.
